9007C62B2 - Square D - Limit Switch

9007C62B2 - Square D Limit Switch

HEAVY DUTY, PLUG-IN, INDUSTRIAL TYPE; DPDT, 2NO-2NC CONTACT CONFIGURATION; 22 TO 12 AWG SCREW CLAMP TERMINAL, 1/2 INCH-14 THREADED CABLE CONNECTION TYPE; SNAP ACTION, SPRING RETURN, CLOCKWISE/COUNTER CLOCKWISE OPERATION TYPE; 600 VOLT AC 10 AMP, 600 VOLT DC 1 AMP CONTACT RATING; UL, CSA, CE APPROVAL; NEMA 1/2/4/6/6P/12/13, IP65/IP66/IP67 ENCLOSURE; DIE-CAST ZINC ALLOY BODY MATERIAL; -20 TO 185 DEG F OPERATING TEMPERATURE; 4 POUND-INCH OPERATING FORCE; 4 DEGREE DIFFERENTIAL TRAVEL; METAL ROTARY LEVER ACTUATOR/HEAD TYPE; 10 DEGREE PRETRAVEL; 90 DEGREE TOTAL TRAVEL; OVERALL DIMENSION 1.54 INCH WIDTH X 4.02 INCH DEPTH X 1.77 INCH HEIGHT; NUMBER OF POLES 2; CONTACT MATERIAL SILVER; SEAL MATERIAL NEOPRENE; 9007C MODEL
