Eaton Cutler-Hammer

Eaton CVS3200X CCV Tenant Main Breaker – 200A, 3-Pole, 42 kAIC

In stock
SKU: CVS3200X GTIN/UPC: 786685704265
$1,254.15
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Eaton CVS3200X CCV tenant main breaker is a molded case circuit breaker designed for commercial tenant main and power distribution applications. It provides reliable thermal magnetic protection against overloads and short-circuit conditions while supporting high interrupting capacity requirements. Its three-pole construction makes it suitable for multi-phase electrical systems in commercial environments.

Electrical Ratings

  • Current Rating: 200A
  • Number of Poles: Three-pole
  • Interrupt Rating: 42 kAIC
  • Circuit Breaker Frame Type: CV
  • Breaker Type: Molded case circuit breaker

Key Specifications

  • Manufacturer: Eaton
  • Catalog Number: CVS3200X
  • UPC: 786685704265
  • Product Type: Tenant main breaker
  • Standards: UL 489, CSA Std. C22.2 No. 5
  • Wire Size Range: #6–4/0 AWG Cu/Al
  • Terminal Capacity: #4/0 kcmil maximum load
  • Application: Commercial tenant main and electrical distribution systems
  • Warranty: Limited lifetime

Physical Details

  • Product Length/Depth: 7.5 in
  • Product Height: 5 in
  • Product Width: 5 in
  • Product Weight: 5 lb

Product Data

  • Application: Commercial power distribution and tenant main protection
  • Compatibility: Eaton CV frame systems
  • Installation Use: Molded case breaker installation
  • Function: Protects electrical systems from overload and short-circuit faults
  • Safety Feature: High 42 kAIC interrupting capacity for enhanced system protection
  • Type Circuit Breakers
  • Vendor Eaton Cutler-Hammer
  • Brand Eaton
