Eaton Quicklag HQP1030R6 30A 1-Pole Thermal Magnetic Circuit Breaker – Plug-On – 120/240V
Couldn't load pickup availability
Ask an expert
The Eaton Quicklag HQP1030R6 thermal magnetic circuit breaker provides dependable overcurrent protection for industrial and commercial electrical systems. Engineered under the Quicklag (Cutler-Hammer) line, this 30 Amp, single-pole breaker is designed for plug-on installation and features a non-interchangeable trip mechanism for reliable circuit protection. With a 10 kAIC interrupt rating and UL 489 listing, it is well suited for demanding industrial applications requiring consistent performance.
Voltage and Rating
- Amperage: 30 Amps
- Voltage: 120/240 Volts AC
- Interrupt Rating: 10 kAIC
- Operating Temperature: 40°C
Key Specifications
- Breaker Type: Thermal Magnetic Circuit Breaker
- Number of Poles: 1-Pole
- Mounting Mode: Plug-On
- Trip Type: Non-Interchangeable
- Product Range: HQP (Quicklag series)
- Applications: Industrial and commercial circuit protection
Technical Specifications
- Wire Size: #14–4 AWG Copper/Aluminum
- Protection Function: Overload and short-circuit protection
- Certifications: UL 489 Listed; Federal Specifications Classification W-C-375b
Product Data
- Manufacturer: Eaton
- Brand: Quicklag (Cutler-Hammer)
- Model Number: HQP1030R6
-
Dimensions:
- Height: 3 in
- Width: 1 in
- Depth: 2.38 in
- Type Circuit Breakers
- Vendor Eaton
- Brand Eaton
