Allen-Bradley 509-EOD 135 Amp Full-Voltage Non-Reversing Motor Starter – 3 Pole – 120V AC Coil – NEMA Size 4

The Allen-Bradley 509-EOD is a Bulletin 509 full-voltage, non-reversing motor starter designed for three-phase motor control. It features a NEMA Size 4 design with a 135A current rating and a 120V AC operating coil. The starter incorporates an eutectic alloy overload relay that requires separately supplied heater elements. Its open construction provides a compact solution for installations where space is limited. Branch-circuit protection and a separate disconnecting means are required.

Specifications

• Brand: Allen-Bradley
• Manufacturer: Rockwell Automation
• Product Series: Bulletin 509
• Catalog Number: 509-EOD
• Product Type: Full-Voltage Non-Reversing Motor Starter
• Number of Poles: 3
• Phase: 3-phase
• Current Rating: 135A
• NEMA Size: 4
• Coil Voltage: 120V AC
• Starter Configuration: Non-reversing
• Starting Method: Full-voltage
• Overload Relay: Eutectic alloy
• Heater Elements: Required; not supplied
• Enclosure Type: Open
• Branch-Circuit Protection: Requires a separate protective device and disconnecting means

Part Numbers & Identification

• Manufacturer: Rockwell Automation
• Brand: Allen-Bradley
• Catalog Number: 509-EOD
• Product Family: Bulletin 509
• Starter Configuration: NEMA non-combination, non-reversing
• UPC:781180218736

Compatibility

Suitable for three-phase motor control applications requiring a NEMA Size 4 full-voltage non-reversing starter with a 120V AC coil. Compatible with the appropriate eutectic alloy overload relay heater elements, which must be selected separately according to the motor's operating requirements. Requires a separate branch-circuit disconnecting means and overcurrent protection.
