800T-PT16W Pilot Light – 30.5mm – 10A – 120VAC – Push-To-Test

The Allen-Bradley 800T-PT16W is a pilot light designed for industrial control and automation systems. It provides reliable visual status indication for machinery and electrical circuits within control panels. This model features a push-to-test (lamp test) function for easy verification of lamp operation. Built as part of the durable 800T series, it supports 120VAC operation with a 10 Amp rating and is suitable for demanding industrial environments.

Voltage and Rating

• Current Rating: 10A
• Voltage Rating: 120VAC

Key Specifications

• Device Type: Pilot Light
• Series: 800T
• Size: 30.5 mm
• Mounting Type: Cartridge
• Connection Type: Screw
• Action: Push-To-Test
• Contact Configuration: 1 NO, 1 NC
• Application: Industrial Control Panels / Motor Control Systems

Technical Specifications

• Wire Gauge: 14–18 AWG
• NEMA Rating: 1, 4, 12, 13
• Temperature Rating: -25°C
• Approvals: ABS, CCC, CE, CSA, EAC, GOST, UL
• Color: White

Product Data

• Manufacturer: Allen-Bradley
• Brand: Allen-Bradley
• Model Number: 800T-PT16W
• Part Number: 800TPT16W
• UPC: 781180187469
• Product Type: Pilot Light
• Product Series: 800T
