The ABB / GE THED136035 is a 35 Amp, 3-pole molded case circuit breaker from the E150 product line, designed for commercial and industrial power distribution applications. Utilizing thermal-magnetic trip protection, this breaker delivers reliable long-time and instantaneous circuit protection for branch and feeder circuits. Rated for up to 600 VAC, it is suitable for high-voltage distribution systems and is approved for reverse feed applications. The compact molded-case design provides dependable circuit interruption and protection in demanding electrical environments.
Voltage and Rating
- Current Rating: 35 Amps
- Voltage Rating: 600 VAC
- Number of Poles: 3
- System Type: 3-Phase
- Device Type: Molded Case Circuit Breaker
Key Specifications
- Product Line: E150 Series
- Breaker Type: THED
- Trip Technology: Thermal Magnetic
- Protection Functions: Long-Time and Instantaneous Protection
- Application: Commercial and industrial power distribution
- Reverse Feed Suitable: Yes
- Brand: ABB / GE
Technical Specifications
- Mounting Type: Molded case breaker installation
- Circuit Protection: Thermal-magnetic trip mechanism
- Conductor Rating:
- 60/75°C rated through 100A
- 75°C rated above 100A
- Lug Compatibility: Cu/Al line and load lugs available with WL suffix models
- Construction Features: Compact molded-case design for reliable protection and switching
Product Data
- Manufacturer: ABB / General Electric
- Catalog Number: THED136035
- UPC: 783164062922
- Product Type: Molded Case Circuit Breaker
- Series: E150 Product Line
Applications
- Industrial power distribution systems
- Commercial electrical panels
- Feeder and branch circuit protection
- Motor and equipment protection
- High-voltage AC distribution applications
- Type Thermal Magnetic
- Vendor GE
- Brand GE
