The ABB / GE THED136090 is a 90 Amp, 3-pole molded case circuit breaker from the E150 product line, engineered for commercial and industrial electrical distribution systems. Featuring thermal-magnetic trip protection, this breaker delivers dependable long-time and instantaneous protection for feeder and branch circuits. Rated for applications up to 600 VAC, it is suitable for demanding high-voltage power distribution environments. The breaker is also approved for reverse feed applications, providing installation flexibility and reliable circuit interruption performance.
Voltage and Rating
- Current Rating: 90 Amps
- Voltage Rating: 600 VAC
- Number of Poles: 3
- System Type: 3-Phase
- Device Type: Molded Case Circuit Breaker
Key Specifications
- Product Line: E150 Series
- Breaker Type: THED
- Trip Technology: Thermal Magnetic
- Protection Functions: Long-Time and Instantaneous Protection
- Application: Commercial and industrial power distribution
- Reverse Feed Suitable: Yes
- Brand: ABB / GE
Technical Specifications
- Mounting Type: Standard molded-case breaker installation
- Circuit Protection: Thermal-magnetic trip mechanism
- Conductor Rating:
- 60/75°C rated through 100A
- 75°C rated above 100A
- Lug Compatibility: Cu/Al line and load lugs available on WL suffix models
- Construction Features: Compact molded-case design for reliable switching and protection
Product Data
- Manufacturer: ABB / General Electric
- Catalog Number: THED136090
- UPC: 783164062991
- Product Type: Molded Case Circuit Breaker
- Series: E150 Product Line
Applications
- Commercial power distribution systems
- Industrial control panels
- Feeder and branch circuit protection
- Motor and equipment disconnect protection
- High-voltage AC electrical systems
- Type Thermal Magnetic
- Vendor GE
- Brand GE
