The ABB / GE THQL32060ST1 is a 60 Amp, 3-pole thermal-magnetic circuit breaker with an integrated shunt trip function for remote tripping capability. Designed for GE Q-Line load centers and PowerMark Gold panelboards, this breaker combines standard overcurrent protection with external control-based disconnect functionality. It is commonly used in safety interlock systems, emergency shutdown circuits, and industrial control applications.
Voltage and Rating
- Current Rating: 60 Amps
- Voltage Rating: 240 VAC
- Number of Poles: 3
- Interrupting Rating: 10 kAIC @ 240 VAC
- Device Type: Shunt Trip Circuit Breaker
Key Specifications
- Series: THQL Q-Line
- Part Number: THQL32060ST1
- Manufacturer: ABB / General Electric
- Breaker Type: Thermal Magnetic with Shunt Trip
- Mounting Style: Plug-On
- Frame Type: THQL
Technical Specifications
- Protection Functions:
- Overload protection
- Short-circuit protection
- Trip Function Code: LI (Long-Time and Instantaneous)
- Shunt Trip Feature: Enables remote tripping via external control circuit
- Trip Adjustability: Fixed thermal and magnetic settings
- Construction Features:
- Quick-make/quick-break mechanism
- Common trip across all three poles
- Visual trip indication
- Compact Q-Line plug-on design
Standards and Approvals
- UL 489 Listed
- CSA Certified
Product Data
- Catalog Number: THQL32060ST1
- UPC: 783164074093
- Series: THQL Q-Line
- Product Type: Shunt Trip Circuit Breaker
Applications
- Emergency shutdown systems
- Fire alarm interface systems
- Industrial control panels
- HVAC and motor control circuits
- Commercial and institutional electrical distribution
- GE Q-Line load centers and PowerMark Gold panel
- Type Circuit Breakers
- Vendor GE
- Brand GE
