ABB / General Electric TEY125 25 Amp 1 Pole Circuit Breaker – Bolt-On – 120/240V AC

In stock
SKU: TEY125 GTIN/UPC: 783164403305
$93.80
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The ABB / General Electric TEY125 25A single-pole circuit breaker is designed for robust commercial and industrial branch circuit protection. Part of the Q-Line TEY series, it features thermal-magnetic trip technology that delivers reliable long-time and instantaneous protection for standard electrical loads. The bolt-on mounting design ensures a secure connection within GE A-Series panelboards, making it suitable for high-performance installations. With a high interrupting capacity of 65kA at 120V, this breaker is engineered to handle demanding fault conditions. It is also HACR and HID rated, making it suitable for specialized HVAC and lighting applications.

Voltage and Rating

  • Current Rating: 25 Amps
  • Voltage Rating: 120VAC, 240VAC, 277VAC, 125VDC, 120/240VAC
  • Interrupting Capacity:
    • 65kA @ 120VAC
    • 14kA @ 240VAC
    • 14kA @ 277VAC
    • 10kA @ 125VDC
    • 14kA @ 120/240VAC
  • Frequency: 50/60 Hz (standard operation)

Key Specifications

  • Breaker Type: Thermal Magnetic Circuit Breaker
  • Trip Function: Long-Time & Instantaneous (LI)
  • Number of Poles: 1-Pole
  • Phase: 1 Phase
  • Mounting Style: Bolt-On
  • Series: TEY Series (Q-Line Family)
  • Application: Commercial/Industrial branch circuit protection
  • Compatible Panelboards: GE A-Series Panelboards
  • Accessories: Shunt Trip, Auxiliary Switch, Undervoltage Release, Bell Alarm, Padlock Attachment

Technical Specifications

  • Wire Size Range: 14–10 AWG (Cu), 12–10 AWG (Al)
  • Max Wire: 10 AWG
  • Min Wire: 14 AWG (Cu), 12 AWG (Al)
  • Terminal Type: Lug Terminals
  • Trip Technology: Thermal-Magnetic
  • Trip Adjustability: Fixed
  • Construction Features: HACR Rated, HID Rated, Non-Interchangeable Trip, Quick-Make/Quick-Break
  • Temperature Rating: 40°C
  • Certifications/Approvals: UL 489, CSA C22.2 No. 5, CSA, HACR, HID, UL Listed

Product Data

  • Manufacturer: ABB / General Electric
  • Series: TEY
  • Part Number: TEY125
  • Type Circuit Breakers
  • Vendor GE
  • Brand General Electric
