The ABB TEY135 35 Amp single-pole circuit breaker is engineered for commercial and industrial power distribution systems requiring dependable and high-performance protection. Part of the TEY series, it features a thermal-magnetic LI (Long-Time and Instantaneous) trip mechanism that ensures reliable overload and short-circuit protection. Designed for bolt-on installation, it provides a secure connection in GE A-Series and ABB ReliaGear lighting panelboards. With a high interrupt rating of 65kA at 120VAC, this breaker is built to handle demanding fault conditions. It also includes HACR and HID certifications, a quick-make/quick-break mechanism to reduce arcing, and a visual trip indicator for fast fault identification.
Voltage and Rating
- Current Rating: 35 Amps
- Voltage Rating: 120VAC, 240VAC, 277VAC, 125VDC, 120/240VAC
- Frequency: 50/60 Hz
- Interrupting Capacity:
- 65kA @ 120VAC
- 14kA @ 240VAC
- 14kA @ 277VAC
- 10kA @ 125VDC
- 14kA @ 120/240VAC
- Phase: 1 Phase
Key Specifications
- Breaker Type: Thermal Magnetic Circuit Breaker
- Trip Function: Long-Time & Instantaneous (LI)
- Number of Poles: 1-Pole
- Mounting Style: Bolt-On
- Series: TEY Series
- Application: Commercial and industrial lighting/power distribution
- Compatible Panelboards: GE A-Series & ABB ReliaGear Lighting Panelboards
- Accessories: Shunt Trip, Auxiliary Switch
- Construction Features: HACR Rated, HID Rated, Quick-Make/Quick-Break, Common Trip, Visual Trip Indicator, Non-Interchangeable Trip
Technical Specifications
- Wire Size Range: 10–4 AWG (Al/Cu)
- Max Wire: 4 AWG
- Min Wire: 10 AWG
- Terminal Type: Load Side Lugs Included
- Trip Technology: Thermal Magnetic
- Trip Adjustability: Fixed Thermal, Fixed Magnetic
- Temperature Rating: 40°C
- Certifications/Approvals: UL 489, CSA C22.2 No. 5, CSA, HACR, HID, UL Listed
Product Data
- Manufacturer: ABB
- Series: TEY
- Amperage: 35A
- Type Thermal Magnetic
- Vendor GE
- Brand GE
