ABB XT1HU3090AFF000XXX 90A 3P Molded Case Circuit Breaker – XT1 Series – Thermal Magnetic – 65kA
Couldn't load pickup availability
Ask an expert
The ABB XT1HU3090AFF000XXX is a 3-pole molded case circuit breaker from the XT1 series, designed for dependable protection in industrial and commercial electrical distribution systems. Rated at 90A, it features a thermal-magnetic trip unit and a compact fixed built-in construction. Engineered for front-side mounting, it provides reliable performance with high breaking capacity and is suitable for panelboard applications.
Voltage and Rating
- Current Rating: 90 A
- Voltage Rating: 600 V
- Voltage Range: 240 to 347 V
- Breaking Capacity: 65 kA
Key Specifications
- Device Type: Molded Case Circuit Breaker
- Series: XT1
- Number of Poles: 3-Pole
- Actuator Type: Toggle
- Connection Type: Bolt Connection
- Mounting Orientation: Front Side
- IP Rating: IP20
- Application: Electrical distribution protection
Technical Specifications
- Trip Technology: Thermal Magnetic
- Construction Type: Built-in device, fixed built-in technique
- Alternate Mfr Part Number: 1SDA074705R1
- Standards Classification: UNSPSC 39120000
- Designed for industrial panelboard installations
- Compact XT1 frame design
Product Data
- Manufacturer: ABB
- Model Number: XT1HU3090AFF000XXX
- Part Number: XT1HU3090AFF000XXX
- Product Type: Molded Case Circuit Breaker
- Product Series: XT1
- UPC: 8015644786823
- Unit of Measure: EA
- Type Circuit Breakers
- Vendor ABB
- Brand ABB
