ABB XT4 250A 3P Molded Case Circuit Breaker – XT4 Series – Thermal Magnetic (TMF) – 100kA @ 480V

Built to handle substantial electrical loads, this 250A molded case circuit breaker is part of the ABB SACE Tmax XT4 family, designed for high-demand commercial and industrial power distribution systems. It serves as a modern replacement for legacy T4L250TW breakers when used with the appropriate retrofit kit, ensuring smooth system upgrades.

This unit-mount MCCB installs into ABB ReliaGear neXT panelboards and ReliaGear SB switchboards. It utilizes fixed thermal and magnetic (TMF) trip elements to provide reliable long-time and instantaneous (LI) protection against overloads and short circuits.

With an impressive interrupting capacity of up to 200kA at 240VAC and 100kA at 480VAC, this current-limiting breaker offers superior fault protection for critical infrastructure. Lugs are not included, allowing flexibility for custom wiring configurations.

Voltage and Rating

• Current Rating: 250 A
• Voltage Ratings: 240VAC, 480VAC, 600VAC, 250VDC, 600VDC
• AIC Rating:
  • 200kA @ 240VAC
  • 100kA @ 480VAC
  • 50kA @ 600VAC
  • 85kA @ 250VDC
  • 75kA @ 600VDC

Key Specifications

• Device Type: Molded Case Circuit Breaker (MCCB)
• Series: XT4 (SACE Tmax XT4)
• Number of Poles: 3-Pole
• Phase: 3 Phase
• Trip Technology: Thermal Magnetic (TMF)
• Trip Function Code: LI
• Trip Function: Long-Time, Instantaneous
• Trip Adjustability: Fixed Thermal, Fixed Magnetic
• Mounting Style: Unit Mount
• Terminal Type: Lugs (Not Included)

Technical Specifications

• Wire Range: 3/0 AWG – 350 kcmil (Cu/Al)
• Max Wire Size: 350 kcmil
• Min Wire Size: 3/0 AWG
• Standards: CSA C22.2 No. 5, IEC 60947-2, UL 489
• Approvals: CCC, CE, CSA, cULus, IEC, KEMA, UL
• Temperature Rating: -25°C to 70°C

Features

• HACR Rated
• Current Limiting Design
• Reverse Feed Capable
