ABB XT5 600A 3P Molded Case Circuit Breaker – XT5 Series – Thermal Magnetic (Adjustable TM) – 65kA @ 480V

Delivering robust power distribution capabilities, this 600A molded case circuit breaker is part of the ABB SACE Tmax XT5 family, built for demanding industrial and commercial applications. It provides a reliable upgrade path for legacy Spectra RMS SG600 and Tmax T5H breakers when used with the appropriate retrofit kits.

This unit-mount MCCB installs into ABB ReliaGear neXT panelboards, ReliaGear SB switchboards, and SACE Tmax XT enclosures. It features an adjustable thermal-magnetic trip unit, allowing customized long-time and instantaneous (LI) protection to match specific system requirements.

With a 65kA interrupting capacity at 480VAC and up to 150kA at 240VAC, this current-limiting breaker ensures strong fault-clearing performance. Front terminals are provided for secure connections, while lugs are not included to support flexible configuration options.

Voltage and Rating

• Current Rating: 600 A
• Amperage Range: 420–600 A
• Voltage Ratings: 600VAC, 600VDC
• AIC Rating:
  • 150kA @ 240VAC
  • 65kA @ 480VAC
  • 35kA @ 600VAC
  • 70kA @ 250VDC
  • 50kA @ 500VDC
  • 35kA @ 600VDC

Key Specifications

• Device Type: Molded Case Circuit Breaker (MCCB)
• Series: XT5 (SACE Tmax XT5)
• Number of Poles: 3-Pole
• Phase: 3 Phase
• Trip Technology: Thermal Magnetic
• Trip Function Code: LI
• Trip Function: Long-Time, Instantaneous
• Trip Adjustability: Adjustable Thermal, Adjustable Magnetic
• Mounting Style: Unit Mount
• Terminal Type: Lugs (Not Included)

Technical Specifications

• Wire Range: 2x 2/0 AWG – 500 kcmil (Cu/Al)
• Standards: CSA C22.2 No. 5, IEC 60947-2, UL 489
• Approvals: CCC, CSA, cULus, IEC, UL
• Temperature Rating: -25°C to 70°C

Features

• HACR Rated
• Current Limiting Design
• Reverse Feed Capable
• Adjustable Trip Settings for Flexible Protection
