Allen-Bradley 104-C16D22 16A 3P Reversing Contactor – DIN Rail Mount – 120VAC Coil

The Allen-Bradley 104-C16D22 is a 3-pole reversing contactor designed for efficient motor control applications. It features a current rating of 16 Amps and supports a maximum voltage of 600 VAC. This IEC open-style contactor includes a 120 VAC coil and built-in auxiliary contacts for enhanced control functionality. The DIN rail mountable design allows for easy installation in industrial control panels and automation systems.

Voltage and Rating

• Current Rating: 16 Amps
• Maximum Voltage Rating: 600 VAC
• Coil Voltage: 120 VAC

Key Specifications

• Device Type: Reversing Contactor
• Number of Poles: 3-Pole
• Phase: 3 Phase
• Standard: IEC
• Mounting Type: DIN Rail Mountable
• Style: Open Style
• Application: Motor Control Systems

Technical Specifications

• Auxiliary Contacts: 1 Normally Open, 1 Normally Closed

Product Data

• Manufacturer: Allen-Bradley
• Model Number: 104-C16D22
• Category: Contactors & Starters
• Subcategory: Contactor
• Weight: 0.87 kgs
