Siemens B310000S01 Molded Case Circuit Breaker – 100A – 3-Pole – 120/240V AC – 10kAIC @ 240V – Bolt-On – BL Series

The Siemens B310000S01 is a 100A, 3-pole molded case circuit breaker from the BL Series. It is designed for electrical distribution applications and features thermal-magnetic protection with long-time and instantaneous (LI) trip functions.

The breaker is rated for 120/240V AC service and provides a 10kA interrupting rating at 240V AC. It uses bolt-on mounting, includes load-side lugs, and is equipped with a 120V AC shunt trip for remote tripping and control applications.

Specifications:

• Manufacturer: Siemens
• Product Type: Molded Case Circuit Breaker
• Catalog No.: B310000S01
• Product Family: BL Series
• Series: BL
• Current Rating: 100A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 120/240V AC
• Interrupting Rating: 10kAIC @ 240V AC
• Protection Type: Thermal-Magnetic
• Trip Functions: Long-Time and Instantaneous (LI)
• Shunt Trip Voltage: 120V AC
• Mounting Type: Bolt-On
• Terminal Connection: Load-Side Lugs
• Wire Range: 4 AWG–1/0 AWG Copper; 2 AWG–1/0 AWG Aluminum
• Actuator: Toggle Handle
• Operating Temperature: 40°C Rating
• Weight: Approx. 1 lb (0.45 kg)
• Dimensions (L × W × H): Approx. 5.7 × 4.6 × 4.1 in
• Application: Electrical Distribution and Remote Tripping/Control
• Brand: Siemens
• Authenticity: Genuine Siemens Product

Part Numbers & Identification:

• Manufacturer Part Number (MPN): B310000S01
• Catalog Number: B310000S01
• Product Family: Siemens BL Series Circuit Breakers
• Series: BL
• Brand: Siemens
• Manufacturer: Siemens
• Product Type: Molded Case Circuit Breaker
• Model: B310000S01
• Configuration: 3-Pole, 100A
• Trip Configuration: Thermal-Magnetic, LI
• Shunt Trip: 120V AC
• Mounting: Bolt-On
• UPC: 783643268623
• GTIN: 00783643268623
• Country of Origin: Mexico
• upc:783643268623

Compatibility:

Designed for use with compatible Siemens BL Series panelboards and electrical distribution systems that accept bolt-on molded case circuit breakers with the specified shunt-trip configuration.

The B310000S01 provides 100A, 3-pole protection for compatible 120/240V AC applications and includes a 120V AC shunt trip for remote tripping or control. It is supplied with load-side lugs and accommodates the specified copper and aluminum conductor ranges.

Always verify the specific panelboard or electrical equipment model, approved breaker type, shunt-trip requirements, system voltage, available fault current, pole configuration, conductor size, terminal arrangement, and installation requirements before installation.

Certifications:

• UL Listed
• CSA Certified
• 100A Rated
• 3-Pole / 3-Phase
• 120/240V AC Rated
• 10kAIC Interrupting Rating @ 240V AC
• Thermal-Magnetic Protection
• LI Long-Time and Instantaneous Trip Functions
• 120V AC Shunt Trip
• Bolt-On Mounting
• Load-Side Lugs
• 40°C Rating
• BL Series
• Genuine Siemens Product
