Siemens B380H00S01 80 Amp Molded Case Circuit Breaker with Shunt Trip – 3 Pole – 120/240 V – 22 kAIC – Type BLH

The Siemens B380H00S01 is an 80 Amp, 3-pole molded case circuit breaker designed for low-voltage electrical distribution and circuit protection applications. It features thermal-magnetic overcurrent protection and a 120 V shunt trip for remote tripping capability. Rated for 120/240 V, this breaker is designed for compatible Siemens panelboards and provides a 22 kA interrupting rating.

Specifications

• Manufacturer: Siemens
• Brand: Siemens
• Product Type: Molded Case Circuit Breaker with Shunt Trip
• Type: BLH
• Catalog Number / MPN: B380H00S01
• Primary Rating: 80 Amp
• Poles / Configuration: 3 Pole
• Voltage: 120/240 V AC
• Shunt Trip Voltage: 120 V
• Trip Type: Thermal-Magnetic
• Interrupting Rating: 22 kAIC
• Connection / Mounting: Panelboard Mounting
• Application: Electrical Distribution
• Standard: UL 489

Part Numbers & Identification

• Manufacturer: Siemens
• Brand: Siemens
• Catalog Number: B380H00S01
• Type: BLH
• Current Rating: 80 A
• Pole Count: 3 Pole
• Product Type: Molded Case Circuit Breaker with Shunt Trip
• Trip Mechanism: Thermal-Magnetic
• Special Feature: 120 V Shunt Trip
• UPC:783643268999

Compatibility

The Siemens B380H00S01 is intended for compatible Siemens panelboards and low-voltage electrical distribution applications requiring a shunt-trip circuit breaker.

Certifications

• UL 489 Listed
