Square D BGA36100 Molded Case Circuit Breaker – 100A – 3-Pole / 3-Phase – 600Y/347V AC – 35kA @ 480V – I-Line Plug-In – PowerPact BGA Series

The Square D BGA36100 is a 100A, 3-pole, 3-phase molded case circuit breaker from the Square D PowerPact BGA Series. It features thermal-magnetic protection with Long-Time and Instantaneous (LI) trip functions and a non-interchangeable trip.

The breaker is rated for 600Y/347V AC and provides a 35kA interrupting rating at 480V. It uses an I-Line style plug-in connection with ABC phase connection and includes load-side mechanical lug terminals.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: PowerPact
• Series: BGA
• Type: BGA
• Catalog No.: BGA36100
• Current Rating: 100A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Phase Connection: ABC
• Voltage Rating: 600Y/347V AC
• Interrupting Rating: 35kA @ 480V
• Protection Type: Thermal-Magnetic
• Trip Functions: Long-Time and Instantaneous (LI)
• Trip Type: Non-Interchangeable
• Mounting / Connection: I-Line Style Plug-In
• Terminal Type: Load-Side Mechanical Lug Terminals
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Square D / Schneider Electric

Part Numbers & Identification:

• Manufacturer Part Number (MPN): BGA36100
• Catalog Number: BGA36100
• Product Family: Square D PowerPact Molded Case Circuit Breakers
• Series: BGA
• Type: BGA
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Model: BGA36100
• Breaker Configuration: 3-Pole, 100A

Compatibility:

Designed for use with compatible Square D PowerPact BGA Series electrical distribution equipment that accepts I-Line style plug-in molded case circuit breakers.

The BGA36100 provides 100A, 3-pole thermal-magnetic protection for compatible 600Y/347V AC applications. It features a 35kA interrupting rating at 480V, non-interchangeable LI trip functions, ABC phase connection, and load-side mechanical lug terminals.

Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, phase connection, terminal arrangement, and installation requirements before installation.
