Square D BJA36040 40 Amp Molded Case Circuit Breaker – 3 Pole – 600Y/347 V – 65 kA@480 V – I-Line Plug-In – PowerPact Series

The Square D BJA36040 is a 40 Amp, 3-pole molded case circuit breaker from the Schneider Electric Square D PowerPact Series, Type BJA. It is rated for 600Y/347 VAC with a 65 kA interrupting rating at 480 V. The breaker features a thermal-magnetic, non-interchangeable trip unit with LI (Long-Time and Instantaneous) protection functions. It is designed for I-Line style plug-in mounting with ABC phase connection and includes load-side mechanical lug terminals.

Specifications

• Manufacturer: Schneider Electric
• Brand: Square D
• Product Type: Molded Case Circuit Breaker
• Series: PowerPact
• Type: BJA
• Catalog Number / MPN: BJA36040
• Primary Rating: 40 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600Y/347 VAC
• Interrupting Rating: 65 kA @ 480 V
• Trip Type: Thermal-Magnetic
• Trip Unit: Non-Interchangeable
• Trip Functions: LI – Long-Time and Instantaneous
• Connection / Mounting: I-Line Style Plug-In
• Phase Connection: ABC
• Terminals: Load-Side Mechanical Lug Terminals

Part Numbers & Identification

• Manufacturer: Schneider Electric
• Brand: Square D
• Catalog Number: BJA36040
• Series: PowerPact
• Type: BJA
• Current Rating: 40 A
• Pole Count: 3 Pole
• Product Type: Thermal-Magnetic Molded Case Circuit Breaker
• Trip Unit: Non-Interchangeable
• Trip Functions: LI – Long-Time and Instantaneous
• Phase Connection: ABC
• UPC:3606481185846

Compatibility

The Square D BJA36040 is designed for compatible Schneider Electric Square D PowerPact BJA electrical distribution applications using I-Line style plug-in mounting. Verify the specific panelboard, system voltage, phase connection, and breaker compatibility before installation.
