BQ2B040H - Siemens Bolt-on 120/240 VACV 40A 2 pole circuit breaker 22kA@240V
Couldn't load pickup availability
Ask an expert
Description
BQ2B040H
The Siemens BQ2B040H is a Molded Case Circuit Breaker. This type BQH circuit breaker is a member of The BQ Series family. The BQ2B040H is a 2 pole, 120/240 VAC Volt, 40 amp rated circuit breaker, with an AIC rating of 22kA@240V. The BQ2B040H is manufactured by Siemens. The BQ2B040H uses a Bolt-on connection. Includes Thermal Magnetic protection. Every part My Circuit Breakers sells is also backed by our industry-leading gold standard 2-year warranty.
Specifications
- Part Number: BQ2B040H
- Manufacturer : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BQ Series
- Type : BQH
- Voltage : 120/240 VAC
- Amperage : 40
- Phase : 1
- Poles : 2
- AIC rating : 22kA@240V
- Connection : Bolt-on
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Lug
- Frame Size : 125A/BQH
- MCM Size : Min. Wire Size 2 AWG (Al), 4 AWG (Cu) Max. Wire Size 1/0 AWG
- Breaker Type : High Interrupting Capacity
- Protection : Thermal Magnetic
Product Data
- UPC : 783643161610
- GTIN : 00783643161610
- Country of Origin : Mexico
- Dimensions : 2 in x 4 in x 4 in
- Weight : 0.75
- Panel Type : Siemens Panelboards
- Standards : CSA Certified, HACR Rated, UL Listed
- Certification : CSA Certified, HACR Rated, UL Listed
- Type Circuit Breakers
- Vendor Siemens / ITE
- Brand Siemens
- Electrical Rating Bolt-On - 40 Amp - 2 Pole - 240 Volt
