CC2175 - Eaton Bolt-On 240V 175A 2 pole circuit breaker 10kA@240V
Couldn't load pickup availability
Ask an expert
Description
CC2175X
The Cutler Hammer CC2175X is a Molded Case Circuit Breaker. This type CC circuit breaker is a member of The CC Series family. The CC2175X is a 2 pole, 240 Volt, 175 amp rated circuit breaker, with an AIC rating of 10kA@240V. The CC2175X is manufactured by Cutler Hammer. The CC2175X uses a Bolt-On connection. Includes Thermal Magnetic protection. Every part My Circuit Breakers sells is also backed by our industry-leading gold standard 2-year warranty.
Specifications
- Part Number: CC2175X
- Manufacturer : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : CC Series
- Type : CC
- Voltage : 240
- Amperage : 175
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
- Type Circuit Breakers
- Vendor Eaton Cutler-Hammer
- Brand Eaton
- Electrical Rating Feed Thru - 175 Amp - 2 Pole - 240 Volt
