Eaton CC3225 Molded Case Circuit Breaker – 200A – 3-Pole – 240V AC – 10kA – Base Mount – CC Series

The Eaton CC3225 is a 200A, 3-pole molded case circuit breaker from Eaton / Cutler-Hammer. It features thermal-magnetic protection and a base-mount configuration for compatible electrical distribution applications.

The CC3225 is rated for 240V AC and provides a 10kA interrupting rating. It includes line terminals for convenient connection and accommodates 2/0 AWG to 300 kcmil copper or aluminum conductors.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer
• Product Type: Molded Case Circuit Breaker
• Catalog No.: CC3225
• Current Rating: 200A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 240V AC
• Interrupting Rating: 10kA
• Protection Type: Thermal-Magnetic
• Mounting Type: Base Mount
• Terminal Type: Line Terminals
• Conductor Material: Copper / Aluminum
• Wire Range: 2/0 AWG – 300 kcmil
• Application: Electrical Distribution and Overcurrent Protection

Part Numbers & Identification:

• Manufacturer Part Number (MPN): CC3225
• Catalog Number: CC3225
• Model: CC3225
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 200A
• UPC:782113266657

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer electrical distribution equipment that accepts the CC3225 molded case circuit breaker. The breaker provides 200A, 3-pole thermal-magnetic protection for compatible 240V AC applications.

The breaker uses a base-mount configuration, includes line terminals, and accommodates 2/0 AWG–300 kcmil copper or aluminum conductors.

Certifications:

• UL Listed
• CSA Certified
• 200A Rated
• 3-Pole / 3-Phase
• 240V AC Rated
• 10kA Interrupting Rating
• Thermal-Magnetic Protection
• Base Mount
• Copper / Aluminum Conductor Compatible
