Eaton CN15BN3CB Contactor – 18A – 3-Pole – 480V/60Hz or 440V/50Hz Coil – NEMA Non-Reversing – Freedom NEMA Series

The Eaton CN15BN3CB is an 18A, 3-pole NEMA non-reversing motor control contactor from the Eaton Cutler-Hammer Freedom NEMA Series. It is a Size 0 contactor designed for compatible motor-control applications.

The CN15BN3CB supports motor loads with maximum horsepower ratings of 1 HP at 115V, 2 HP at 230V, 3 HP at 208/240V, and 5 HP at 480/600V. The available information specifies a 480V/60Hz or 440V/50Hz coil voltage.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer
• Product Type: Motor Control Contactor
• Product Family: Freedom NEMA
• Series: Freedom NEMA Series
• Catalog No.: CN15BN3CB
• Current Rating: 18A
• Number of Poles: 3-Pole
• Contactor Type: NEMA Non-Reversing
• NEMA Size: Size 0
• Coil Voltage: 480V AC @ 60Hz / 440V AC @ 50Hz
• Maximum Horsepower: 1 HP @ 115V; 2 HP @ 230V; 3 HP @ 208/240V; 5 HP @ 480/600V
• Application: Motor Control
• Brand: Eaton / Cutler-Hammer

Part Numbers & Identification:

• Manufacturer Part Number (MPN): CN15BN3CB
• Catalog Number: CN15BN3CB
• Model: CN15BN3CB
• Product Family: Eaton Freedom NEMA Contactors
• Series: Freedom NEMA Series
• Brand: Eaton
• Manufacturer: Eaton / Cutler-Hammer
• Product Type: NEMA Motor Control Contactor
• Configuration: 3-Pole, 18A
• NEMA Size: Size 0
• UPC:782113777528

Compatibility:

Designed for use in compatible Eaton / Cutler-Hammer Freedom NEMA motor-control applications requiring a Size 0, 3-pole, non-reversing contactor. The CN15BN3CB is suitable for motor applications within the specified horsepower ratings and coil-voltage requirements.

Always verify the specific motor load, system voltage, horsepower, coil voltage and frequency, control-circuit requirements, enclosure, mounting arrangement, and applicable installation requirements before installation.

Certifications:

• Freedom NEMA Series
• 18A Rated
• 3-Pole
• NEMA Non-Reversing Contactor
• Size 0
• 480V/60Hz or 440V/50Hz Coil
• 1 HP @ 115V
• 2 HP @ 230V
• 3 HP @ 208/240V
• 5 HP @ 480/600V
• Eaton / Cutler-Hammer Product
