Eaton Cutler-Hammer CRD320T33W 2000 Amp Molded Case Circuit Breaker – 3 Pole – 600V AC – 65 kA @ 480V – Series C

The Eaton Cutler-Hammer CRD320T33W is a 2000A, three-pole molded case circuit breaker from the Series C family. Designed for high-capacity electrical distribution, it features a bolt-on mounting configuration and a 100% rated design for continuous-current applications. The breaker is equipped with a Digitrip RMS 310 solid-state electronic trip unit providing Long-Time and Short-Time (LS) protection functions.

Specifications

• Brand: Eaton / Cutler-Hammer / Westinghouse
• Product Series: Series C
• Circuit Breaker Type: CRD
• Amperage Rating: 2000A
• Poles: 3
• Phase: 3-phase
• Voltage Rating: 600V AC
• Interrupting Capacity: 65 kA @ 480V AC
• Interrupting Class: Standard interrupting capacity
• Mounting: Bolt-on
• Current Rating: 100% rated
• Trip Unit: Digitrip RMS 310
• Trip Unit Type: Solid-state electronic
• Trip Functions: LS – Long-Time and Short-Time

Part Numbers & Identification

• Manufacturer Part Number (MPN): CRD320T33W
• Brand: Eaton / Cutler-Hammer
• Series: C
• Type: CRD
• UPC:786679547182

Compatibility

Designed for compatible Eaton Cutler-Hammer Series C CRD-frame installations requiring a 2000A, three-pole circuit breaker with Digitrip RMS 310 electronic LS protection. Separate line and load lugs and a compatible rating plug are required for installation and operation.
