Eaton CVH3225X3 225 Amp Molded Case Circuit Breaker – 3 Pole – 100 kAIC – Type CV

The Eaton CVH3225X3 is a 225 Amp, 3-pole molded case circuit breaker from the Eaton Type CV product range. It provides a 100 kA interrupting capacity and supports aluminum or copper conductors. The breaker accommodates load conductors up to 300 kcmil maximum.

Specifications

• Manufacturer: Eaton
• Brand: Eaton
• Product Type: Molded Case Circuit Breaker
• Type: CV
• Catalog Number / MPN: CVH3225X3
• Primary Rating: 225 Amp
• Poles / Configuration: 3 Pole
• Interrupting Rating: 100 kAIC
• Conductor Material: Aluminum / Copper
• Conductor Size Range: #6 AWG–4/0 AWG
• Maximum Load Conductor Size: 300 kcmil

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Eaton
• Catalog Number: CVH3225X3
• Type: CV
• Current Rating: 225 A
• Pole Count: 3 Pole
• Product Type: Molded Case Circuit Breaker
• Interrupting Rating: 100 kAIC
• UPC:786685705170

Compatibility

The Eaton CVH3225X3 is intended for compatible Eaton Type CV electrical distribution applications using supported aluminum or copper conductors.
