Eaton A1X1PK Series C Auxiliary Switch Factory Kit – F-Frame HMCP (1A-1B, Pigtail Leads)

The Eaton A1X1PK is a molded case circuit breaker accessory auxiliary switch factory installation kit designed for use with F-frame HMCP breakers in Series C systems. It provides reliable auxiliary contact signaling for breaker status monitoring, including open/closed indication. Featuring pigtail lead connections and a 1A-1B contact configuration, this accessory supports flexible installation in left, right, or neutral mounting positions for enhanced system integration and operational monitoring.

Voltage and Rating

• Application Type: Auxiliary Switch
• Contact Configuration: 1A-1B
• Mounting Options: Left, Right, Neutral
• Frame Compatibility: Frame J-K (F-frame HMCP breakers)
• Series: Series C

Key Specifications

• Manufacturer: Eaton
• Catalog Number: A1X1PK
• Product Type: Molded Case Circuit Breaker Accessory
• Type: Auxiliary Switch Factory Installation Kit
• Connection Type: Pigtail Leads
• Used With: F-frame HMCP breakers
• Function: Breaker status indication and auxiliary signaling
• Special Features: Pigtail leads included
• Compliance: Contact Manufacturer

Physical Details

• Product Length/Depth: 2.9 in
• Product Height: 3.2 in
• Product Width: 5.5 in
• Product Weight: 0.25 lb

Product Data

• UPC: 786679161135
• Category: Circuit Breaker Accessories
• Application: Auxiliary contact signaling for molded case circuit breakers
• System Use: Series C HMCP breaker systems
• Warranty: Eaton Selling Policy 25-000, one (1) year from installation or eighteen (18) months from shipment, whichever occurs first
