Eaton BAB3080H 80A 3-Pole Thermal-Magnetic Breaker – Bolt-On – 240V

The Eaton Quicklag BAB3080H circuit breaker delivers dependable 80A, 3-pole thermal-magnetic protection for 240V circuits. Designed for Eaton Quicklag load centers and panelboards, this bolt-on breaker provides rugged performance for commercial and industrial electrical distribution. Its high-capacity lug terminals and 10 kA interrupt rating ensure reliable protection and long-term durability.

Voltage and Rating

• Amperage: 80 Amps
• Poles: 3-Pole
• Voltage Rating: 240 Volts AC
• Interrupting Capacity: 10 kAIC

Key Specifications

• Breaker Type: Thermal-Magnetic
• Mounting Type: Bolt-On
• Product Range: Quicklag
• Application: Commercial and industrial branch circuit protection
• Compatible Panels: Eaton Quicklag load centers and panelboards

Technical Specifications

• Wire Size Range: #4–2/0 AWG Copper/Aluminum
• Connection Terminals: Lug terminals
• Terminal Tightening Torque: 70 lb-in
• Certifications: UL Listed, CSA Certified, HACR Rated

Product Data

• Manufacturer: Eaton
• Brand: Eaton
• Model Number: BAB3080H
• UPC: 786679303801

Dimensions

• • Height: 4.7 in
  • Width: 3.2 in
  • Depth: 3.8 in
  • Weight: 1.0 lbs
