Eaton BQC2152120 BR Thermal Magnetic Circuit Breaker – 15A/20A, 4-Pole, 120/240V

The Eaton BQC2152120 thermal magnetic circuit breaker is designed for reliable branch circuit protection in Type BR loadcenters. This Type BQC quadplex breaker combines two 20A single-pole breakers and one 15A two-pole breaker in a compact four-pole configuration, making it suitable for residential electrical applications. Featuring a plug-on mounting design and rejection tab feature, it ensures secure installation and dependable performance for HACR-rated systems.

Voltage and Rating

• Current Rating: (2) Single-Pole 20A, (1) Two-Pole 15A
• Voltage Rating: 120/240 V
• Interrupt Rating: 10 kAIC
• Number of Poles: Four-pole
• Trip Type: Common breaker trip
• Circuit Breaker Type: BQ
• Mounting Method: Plug-on

Key Specifications

• Manufacturer: Eaton
• Catalog Number: BQC2152120
• UPC: 786676371957
• Product Type: Thermal magnetic circuit breakers
• Type: Type BQC 1-Inch CTL plug-on circuit breaker
• Used With: Type BR Loadcenters
• Main Circuit Breaker: BQC
• Wire Size: #14-4 AWG Cu/Al
• Certifications: UL 489
• Compliances: Federal Specifications Classification W-C375
• Quantity: 28
• Special Features: Includes rejection tab feature
• Catalog Notes: All Type BD Duplex and BQ Quadplex circuit breakers carry listing for HACR applications. All 15 and 20 ampere single poles are switch duty rated.

Physical Details

• Product Length/Depth: 2.5 in
• Product Height: 3.2 in
• Product Width: 2 in
• Product Weight: 0.8 lb

Product Data

• Application: Residential branch circuit protection
• Compatibility: Eaton Type BR Loadcenters
• Mounting Style: Plug-on design
• HACR Rated: Yes
