Eaton BQC2302130 BR Thermal Magnetic Circuit Breaker – 30A, 4-Pole, 120/240V

The Eaton BQC2302130 thermal magnetic circuit breaker is a Type BQC quad breaker designed for reliable branch circuit protection in Type BR loadcenters. This unit combines one 30A two-pole breaker and two 30A two-pole breakers with a common trip configuration, delivering dependable performance for residential electrical applications. Built for plug-on installation, it ensures secure mounting and consistent operation in HACR-rated systems.

Voltage and Rating

• Current Rating: (2) Two-Pole 30A, (1) Two-Pole 30A (Common Trip)
• Voltage Rating: 120/240V
• Interrupt Rating: 10 kAIC
• Number of Poles: Four-pole
• Trip Type: Common breaker trip
• Circuit Breaker Type: BQC
• Mounting Method: Plug-on

Key Specifications

• Manufacturer: Eaton / Cutler-Hammer
• Catalog Number: BQC2302130
• Alternate Part No: EATON CORPORATION CUTLER HAMMER 68C9915G45
• Product Type: Thermal magnetic circuit breakers
• Type: Type BQC quad breaker
• Used With: Type BR Loadcenters
• Main Circuit Breaker: BQC
• Voltage Rating: 120/240V
• Interrupt Rating: 10 kAIC
• Certifications: UL 489
• Compliances: Federal Specifications Classification W-C375
• Quantity: 28
• Special Features: Common trip design
• Warranty: Radwell 2-year warranty included (factory warranty may not apply)
• Catalog Notes: All Type BD Duplex and BQ Quadplex circuit breakers carry listing for HACR applications. All 15 and 20 ampere single poles are switch duty rated.

Physical Details

• Product Length/Depth: 3 in
• Product Height: 3 in
• Product Width: 2 in
• Product Weight: 0.9 lb

Product Data

• Application: Residential branch circuit protection
• Compatibility: Eaton Type BR Loadcenters
• Mounting Style: Plug-on design
• HACR Rated: Yes
