Eaton BR150 50A 1-Pole Thermal Magnetic – Plug-On – 120/240V

The Eaton BR150 is a 50 Amp, 1-pole thermal-magnetic circuit breaker designed for Type BR loadcenters and panels. With a 10kAIC interrupt rating and plug-on mounting, it delivers reliable overcurrent protection for residential and commercial 120/240V circuits. UL 489 listed and compliant with federal specifications, it is ideal for standard BR loadcenter applications.

Voltage and Rating:

• Current Rating: 50 Amps
• Voltage Rating: 120/240 Volts AC
• Interrupting Capacity: 10 kAIC

Key Specifications:

• Breaker Type: Thermal Magnetic Circuit Breaker
• Number of Poles: 1-Pole
• Mounting Mode: Plug-On
• Wire Size: #14–4 AWG Cu/Al
• Application: Residential and commercial circuit protection
• Special Features: Compatible with Type BR Loadcenters
• Certifications: UL 489, Federal Specifications Classification W-C375

Physical Specifications:

• Dimensions (H × W × D): 3 × 1 × 3 in
• Weight: 0.3 lbs

Product Data

Manufacturer: Eaton
Brand: Eaton
Model Number: BR150
UPC: 786676362306
Range: BR Series (For Type BR loadcenters and panels)
