Eaton Cutler-Hammer

Eaton BR230ST BR Thermal Magnetic Circuit Breaker – 30A, 2-Pole, 120/240V

In stock
SKU: BR230ST GTIN/UPC: 786676000239
$148.40
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Eaton BR230ST thermal magnetic circuit breaker is a Type BR plug-on breaker designed for dependable branch circuit protection in Eaton Type BR loadcenters. This 2-pole 30A breaker features thermal magnetic overcurrent protection along with an integrated 120VAC shunt trip function, enabling remote tripping capability for enhanced control and safety in residential and light commercial electrical systems.

Voltage and Rating

  • Current Rating: 30A
  • Voltage Rating: 120/240V
  • Interrupt Rating: 10 kAIC
  • Number of Poles: Two-pole
  • Trip Type: Common breaker trip
  • Circuit Breaker Type: BR
  • Mounting Method: Plug-on
  • Shunt Trip: Included (120VAC)

Key Specifications

  • Manufacturer: Eaton
  • Catalog Number: BR230ST
  • UPC: 786676000239
  • Product Type: Thermal magnetic circuit breaker
  • Type: Type BR breakers
  • Used With: Type BR Loadcenters
  • Main Circuit Breaker: BR
  • Wire Size: #14–4 AWG Cu/Al
  • Certifications: UL 489
  • Compliances: Federal Specifications Classification W-C375
  • Quantity: 28
  • Special Features: 120VAC shunt trip

Physical Details

  • Product Length/Depth: 4.5 in
  • Product Height: 4 in
  • Product Width: 4.25 in
  • Product Weight: 1 lb

Product Data

  • Application: Residential and light commercial branch circuit protection with remote tripping capability
  • Compatibility: Eaton Type BR Loadcenters
  • Mounting Style: Plug-on design
  • HACR Rated: Yes
  • Type Thermal Magnetic
  • Vendor Eaton Cutler-Hammer
  • Brand Eaton
