Eaton BRCAF120CS BR AFCI Circuit Breaker – 20A, Single-Pole, 120V
Couldn't load pickup availability
Ask an expert
The Eaton BRCAF120CS AFCI circuit breaker is designed for use with Eaton Type BR loadcenters, providing advanced arc fault protection for residential electrical systems. This single-pole 20A breaker helps detect and interrupt hazardous arc faults to reduce the risk of electrical fires. Featuring a pigtail connection design and supplied in a clamshell pack, it offers dependable protection and easy installation for branch circuit applications.
Voltage and Rating
- Current Rating: 20A
- Voltage Rating: 120V
- Interrupt Rating: 10 kAIC
- Number of Poles: Single-pole
- Circuit Breaker Type: AFCI
- Connection Type: Pigtail
Key Specifications
- Manufacturer: Eaton
- Catalog Number: BRCAF120CS
- UPC: 786685514376
- Product Type: AFCI circuit breaker
- Type: AFCI circuit breaker
- Used With: Type BR Loadcenters
- Main Circuit Breaker: BR
- Wire Size: #14–4 AWG Cu/Al
- Certifications: UL 1699
- Compliances: Federal Specifications Classification W-C375
- Quantity: 30
- Special Features: Clamshell pack
- Warranty: Limited lifetime residential, 1 year commercial
Physical Details
- Product Length/Depth: 6 in
- Product Height: 1.25 in
- Product Width: 3.5 in
- Product Weight: 0.45 lb
Product Data
- Application: Residential arc fault circuit protection
- Compatibility: Eaton Type BR Loadcenters
- Mounting Style: Plug-on design
- Type Circuit Breakers
- Vendor Eaton Cutler-Hammer
- Brand Eaton
