Eaton BRH220 BR Thermal Magnetic Circuit Breaker – 20A, 2-Pole, 120/240V

The Eaton BRH220 thermal magnetic circuit breaker is a Type BR high interrupting capacity plug-on breaker designed for use with Eaton Type BR loadcenters. This 2-pole 20A breaker provides dependable overcurrent protection with a common trip mechanism, making it suitable for residential and light commercial electrical systems requiring higher interrupting capacity performance.

Voltage and Rating

• Current Rating: 20A
• Voltage Rating: 120/240V
• Interrupt Rating: 22 kAIC
• Number of Poles: Two-pole
• Trip Type: Common breaker trip
• Circuit Breaker Type: BR
• Mounting Method: Plug-on

Key Specifications

• Manufacturer: Eaton
• Catalog Number: BRH220
• UPC: 786676373500
• Product Type: Thermal magnetic circuit breaker
• Type: Type BR 1-Inch plug-on circuit breaker
• Used With: Type BR Loadcenters
• Main Circuit Breaker: BRH
• Wire Size: #14–4 AWG Cu/Al
• Certifications: UL 490
• Compliances: Federal Specifications Classification W-C376
• Quantity: 28
• Catalog Notes: 10–150A single-, two-, and three-pole breakers available in switching duty, HACR, shunt trip, and high magnetic settings

Physical Details

• Product Length/Depth: 3 in
• Product Height: 3 in
• Product Width: 2 in
• Product Weight: 0.6 lb

Product Data

• Application: Residential and light commercial branch circuit protection
• Compatibility: Eaton Type BR Loadcenters
• Mounting Style: Plug-on design
• Protection Type: Thermal magnetic protection
