Eaton Cutler-Hammer

Eaton BRH230 BR Thermal Magnetic Circuit Breaker – 30A, 2-Pole, 120/240V

In stock
SKU: BRH230 GTIN/UPC: 786676373609
$78.40
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Eaton BRH230 thermal magnetic circuit breaker is a Type BR high-magnetic plug-on breaker designed for use with Eaton Type BR loadcenters. This 2-pole 30A breaker provides reliable overcurrent protection with a high-magnetic trip setting, making it suitable for applications with high inrush current requirements. Featuring a common trip mechanism and plug-on mounting design, it delivers dependable performance in residential and light commercial electrical systems.

Voltage and Rating

  • Current Rating: 30A
  • Voltage Rating: 120/240V
  • Interrupt Rating: 22 kAIC
  • Number of Poles: Two-pole
  • Trip Type: Common breaker trip
  • Circuit Breaker Type: BR
  • Mounting Method: Plug-on

Key Specifications

  • Manufacturer: Eaton
  • Catalog Number: BRH230
  • UPC: 786676373609
  • Product Type: Thermal magnetic circuit breaker
  • Type: Type BR 1-Inch plug-on high-magnetic circuit breaker
  • Used With: Type BR Loadcenters
  • Main Circuit Breaker: BRH
  • Wire Size: #14–4 AWG Cu/Al
  • Certifications: UL 490
  • Compliances: Federal Specifications Classification W-C376
  • Quantity: 28
  • Special Features: High-magnetic trip setting
  • Catalog Notes: 10–150A single-, two-, and three-pole breakers available in switching duty, HACR, shunt trip, and high-magnetic configurations

Physical Details

  • Product Length/Depth: 3 in
  • Product Height: 3 in
  • Product Width: 2 in
  • Product Weight: 0.6 lb

Product Data

  • Application: Branch circuit protection for high inrush current applications
  • Compatibility: Eaton Type BR Loadcenters
  • Mounting Style: Plug-on design
  • Protection Type: High-magnetic thermal magnetic protection
  • Type Thermal Magnetic
  • Vendor Eaton Cutler-Hammer
  • Brand Eaton
