The Eaton BRHH2100 100 Amp double-pole thermal-magnetic circuit breaker provides heavy-duty overcurrent and short-circuit protection for residential, commercial, and industrial electrical systems. Designed for Eaton Type BR load centers, it features a plug-on connection and plug-in mounting style for secure and convenient installation.
With a high interrupt rating of 42kA, the BRHH2100 is ideal for circuits requiring robust protection, safeguarding both wiring and connected equipment. UL 489 certification and Federal Specification W-C376 compliance ensure adherence to industry safety standards.
Voltage & Rating
- Current Rating: 100 Amps
- Voltage Rating: 120/240 Volts AC
- Interrupting Capacity: 42 kAIC
Key Specifications
- Breaker Type: Thermal-Magnetic Circuit Breaker
- Number of Poles: 2-Pole
- Mounting Type: Plug-In
- Connection Type: Plug-On
- Application: Residential, commercial, and industrial branch circuit protection
- Certifications: UL 489, Federal Specifications Classification W-C376
Technical Specifications
- Wire Size: #4–1/0 AWG Copper/Aluminum
- Operating Temperature: -10°C to +60°C
- Operating Mechanism: Thermal-magnetic
Product Data
-
- Manufacturer: Eaton
- Model Number: BRHH2100
- UPC: 786676376952
- Weight: 0.6 lb
- Type Circuit Breakers
- Vendor Eaton
- Brand Eaton
