Eaton Bussmann FWH-35A 35A High Speed Fuse – Blade End – 1000VAC / 800VDC
Couldn't load pickup availability
Ask an expert
The Eaton Bussmann FWH-35A is a high-speed fuse designed for semiconductor and power electronics protection. With a 35A current rating, it provides fast-acting fault interruption to protect sensitive equipment such as drives, rectifiers, and power converters. Its compact blade-end construction ensures secure installation and reliable performance in high-voltage AC/DC applications.
Voltage and Rating
- Current Rating: 35A
- Voltage Rating: 1000VAC / 800VDC
- Fuse Type: High Speed Fuse
- Fuse Indicator: Non-Indicating
Key Specifications
- Manufacturer: Eaton Bussmann
- Catalog Number: FWH-35A
- Product Type: High Speed Fuse
- Connection Type: Blade End x Blade End
- Application: Semiconductor Protection, Power Converters, DC Drives, Rectifiers
- Compliance: RoHS Compliant (Contact Factory for additional approvals)
Technical Specifications
- Interrupt Characteristics: High-speed clearing for semiconductor protection
- Construction Type: Industrial-grade fuse element
- Electrical Performance: Designed for high fault current protection in AC/DC systems
- Packaging Type: Standard
Physical Details
- Product Length/Depth: 0.88 in
- Product Height: 3.45 in
- Product Width: 0.93 in
- Product Weight: 0.12 lb
Product Data
- Manufacturer: Eaton Bussmann
- UPC: 051712150002
- Category: High Speed Fuses
- Warranty: Not Applicable
- Type Circuit Breakers
- Vendor Eaton Bussmann
- Brand Eaton Bussmann
