Eaton Bussmann FWX-70A 70A High Speed Fuse – Stud Mount – 600V

The Eaton Bussmann FWX-70A is a high-speed fuse designed for semiconductor protection in industrial power electronic systems. With a 70A RMS rating, it provides fast-acting fault interruption to protect sensitive equipment such as DC drives, rectifiers, and power converters. Its stud-mount configuration with blade end connections ensures secure installation and reliable performance in demanding electrical environments.

Voltage and Rating

• Current Rating: 70A RMS
• Voltage Rating: 600 V
• Interrupt Rating: 200 kAIC (VAC), 50 kAIC @ 250VDC
• Fuse Type: High Speed Fuse

Key Specifications

• Manufacturer: Eaton Bussmann
• Catalog Number: FWX-70A
• Product Type: High Speed Fuse
• Fuse Indicator: Non-Indicating
• Mounting Method: Stud Mount
• Connection Type: Blade End x Blade End
• Application: Semiconductor Protection, DC Drives, Power Converters, Rectifiers
• Compliance: CE Marked, RoHS Compliant

Technical Specifications

• Watt Losses: 7.2 W
• Interrupt Characteristics: Fast-acting semiconductor protection
• Electrical Performance: High fault current interruption capability
• Construction Type: Industrial-grade fuse element
• Packaging Type: Standard

Physical Details

• Product Length/Depth: 3.11 in
• Product Height: 3.11 in
• Product Width: 1.23 in
• Product Weight: 0.3 lb

Product Data

• Manufacturer: Eaton Bussmann
• UPC: 051712150606
• Category: High Speed Fuses
• Certifications: UL Recognized, CSA Certified
• Warranty: Not Applicable
