Eaton BWH2225 BW Main Circuit Breaker – 225A, 2-Pole, 120/240V, Bolt-On Service Entrance Breaker

In stock
SKU: BWH2225 GTIN/UPC: 786679122563
$389.20
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Eaton BWH2225 BW main circuit breaker is a high-capacity thermal magnetic breaker designed for service entrance applications. Rated at 225A with a 25 kAIC interrupting capacity, it provides reliable long-time and instantaneous overcurrent protection. This bolt-on breaker is designed for installation in Eaton Type BR load centers, ECB unit enclosures, and modular meter stacks, making it suitable for residential and commercial main service protection. A legacy BWH frame, it is often replaced in modern systems by the CSR2225N.

Voltage and Rating

  • Current Rating: 225A
  • Voltage Rating: 120/240V AC
  • Interrupt Rating: 25 kAIC @ 120/240V
  • Number of Poles: Two-pole
  • Phase: Single-phase
  • Trip Function: Long-time and instantaneous (LI)
  • Trip Technology: Thermal magnetic
  • Trip Adjustability: Fixed

Key Specifications

  • Manufacturer: Eaton / Cutler-Hammer
  • Series: BWH
  • Part Number: BWH2225
  • Product Type: Main circuit breaker
  • Mounting Style: Bolt-on
  • Terminal Type: Lugs
  • Wire Range: 2 AWG – 300 kcmil Cu/Al
  • Max Wire Size: 300 kcmil
  • Min Wire Size: 2 AWG
  • For Use With: Eaton Type BR load centers, ECB unit enclosures, meter stacks, meter breakers
  • Standards: UL 489, Federal Specification W-C375
  • Approval: UL, CSA
  • Temperature Rating: 40°C
  • Construction Features: HACR rated, high interrupting capacity, main breaker design
  • Available Options: Shunt trip, auxiliary switch, bell alarm
  • Accessories: Lugs included

Product Data

  • Application: Service entrance main breaker protection
  • Compatibility: Eaton Type BR load center systems
  • Installation Style: Bolt-on main breaker configuration
  • Performance Feature: High interrupting capacity (25 kAIC) with service entrance duty rating
  • Type Circuit Breakers
  • Vendor Eaton Cutler-Hammer
  • Brand Eaton
