Eaton Cutler-Hammer

Eaton CCV2060 CCV Tenant Main Circuit Breaker – 60A, 2-Pole, 120/240V

In stock
SKU: CCV2060 GTIN/UPC: 786680146046
$317.80
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Eaton CCV2060 CCV tenant main breaker is designed for tenant service applications in Eaton Type ECC unit enclosures. This 2-pole 60A circuit breaker provides reliable overcurrent protection with a thermal magnetic trip mechanism and is rated for 10 kAIC interrupting capacity. It is built for secure tenant disconnect and main protection duties in residential and light commercial metering and distribution systems.

Voltage and Rating

  • Current Rating: 60A
  • Voltage Rating: 120/240V AC
  • Interrupt Rating: 10 kAIC
  • Number of Poles: Two-pole
  • Circuit Breaker Frame Type: CCV

Key Specifications

  • Manufacturer: Eaton
  • Catalog Number: CCV2060
  • UPC: 786680146046
  • Product Type: Tenant main circuit breaker
  • Type: Tenant main breaker
  • Used With: Type ECC unit enclosures
  • Standards: UL 489, CSA Std. C22.2 No. 5
  • Wire Size: #2/0 AWG – 300 kcmil Cu/Al
  • Application: Tenant service main disconnect

Physical Details

  • Product Length/Depth: 8 in
  • Product Height: 5.5 in
  • Product Width: 4.5 in
  • Product Weight: 3 lb

Product Data

  • Application: Tenant main service protection and disconnect
  • Compatibility: Eaton ECC unit enclosure systems
  • Mounting Style: Enclosure-mounted breaker assembly
  • Protection Type: Thermal magnetic overcurrent protection
  • Type Circuit Breakers
  • Vendor Eaton Cutler-Hammer
  • Brand Eaton
