Eaton Cutler-Hammer

Eaton CCVH2225 CCV Tenant Main Circuit Breaker – 225A, 2-Pole, 120/240V, 25 kAIC

In stock
SKU: CCVH2225 GTIN/UPC: 786685368672
$628.60
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Eaton CCVH2225 CCV tenant main breaker is designed for tenant service applications in Eaton Type ECC unit enclosures. It provides reliable main disconnect and overcurrent protection for high-capacity tenant electrical systems. With a thermal magnetic trip mechanism and a 25 kAIC interrupt rating, it delivers strong fault protection and dependable performance in residential and commercial power distribution applications.

Voltage and Rating

  • Current Rating: 225A
  • Voltage Rating: 120/240V AC
  • Interrupt Rating: 25 kAIC
  • Number of Poles: Two-pole
  • Circuit Breaker Frame Type: CCV
  • Protection Type: Thermal magnetic overcurrent protection

Key Specifications

  • Manufacturer: Eaton
  • Catalog Number: CCVH2225
  • UPC: 786685368672
  • Product Type: Tenant main circuit breaker
  • Used With: Type ECC unit enclosures
  • Standards: UL 489 certified
  • Wire Size: #2/0 AWG – 300 kcmil Cu/Al
  • Terminal Type: Standard lugs (copper or aluminum)
  • Application: Tenant service main protection and disconnect
  • Type: Tenant main breaker

Physical Details

  • Product Length/Depth: 7.7 in
  • Product Height: 5.4 in
  • Product Width: 4.5 in
  • Product Weight: 2.9 lb

Product Data

  • Application: Tenant electrical service main disconnect
  • Compatibility: Eaton ECC unit enclosure systems
  • Installation Use: Main breaker for tenant distribution panels
  • Function: Provides primary overcurrent and fault protection for tenant load circuits
  • Type Circuit Breakers
  • Vendor Eaton Cutler-Hammer
  • Brand Eaton
