Eaton Cutler-Hammer

Eaton CE15MN3A XT IEC Contactor – 105A, 3-Pole, 110–120VAC Coil, 160mm Frame

In stock
SKU: CE15MN3A GTIN/UPC: 782113604022
$1,084.05
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Eaton CE15MN3A XT IEC contactor is a heavy-duty, non-reversing contactor designed for industrial motor control and power switching applications. Part of the Eaton Freedom XT IEC series, it provides reliable operation for higher horsepower loads and demanding control environments. With a 160 mm frame size and a 110–120VAC coil, it is suitable for robust industrial control panels requiring durable switching performance.

Electrical Ratings

  • Continuous Current Rating: 105A
  • Amperage Rating: 105A
  • Maximum Horsepower Rating: 10 hp
  • Frequency Rating: 50–60 Hz
  • Coil Voltage: 110–120VAC (50–60 Hz)
  • Number of Poles: Three-pole
  • Operation Type: Non-reversing
  • Overload Relay: Not included

Key Specifications

  • Manufacturer: Eaton
  • Catalog Number: CE15MN3A
  • UPC: 782113604022
  • Product Type: Contactor
  • Series: Freedom XT IEC
  • Frame Size: 160 mm
  • Mounting Method: Steel mounting plate
  • Certifications: IEC Rated, UL Listed, CSA Certified
  • Compliances: ISO 9000, DIN VDE 0600
  • Warranty: 1 year (Eaton Selling Policy 25-000)
  • Catalog Notes: No enclosure included
  • Accessories: No enclosure

Physical Details

  • Product Length/Depth: 5.94 in
  • Product Height: 7.17 in
  • Product Width: 4.08 in
  • Product Weight: 8.05 lb

Product Data

  • Application: Industrial motor control and power switching
  • Compatibility: Heavy-duty IEC control panels and automation systems
  • Installation Use: Steel mounting plate for industrial assemblies
  • Function: Provides reliable switching for high-load motors and equipment
  • Type Contactor
  • Vendor Eaton Cutler-Hammer
  • Brand Eaton
