Eaton

Eaton CHFN120DF 20A 1-Pole Dual-Function AFCI/GFCI Circuit Breaker – Pigtail Neutral – 120V AC

In stock
SKU: CHFN120DF GTIN/UPC: 786689058852
$66.25
SELECT ITEM CONDITION
Secure transaction
FREE & fast shipping on orders over $99
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Eaton CHFN120DF is a 1-pole dual-function circuit breaker that combines arc-fault and ground-fault protection in a single device. Designed for use in Eaton CH series load centers, it helps protect wiring and connected equipment by detecting both arc faults and ground faults and disconnecting power when unsafe conditions occur.

Featuring a pigtail neutral connection and dependable thermal-magnetic operation, this breaker delivers reliable protection and consistent performance in 120V AC systems.

Voltage and Ratings

  • Voltage Rating: 120 Volts AC
  • Current Rating: 20 Amps
  • Interrupting Capacity: 10 kA

Key Specifications

  • Product Type: Miniature Circuit Breaker
  • Breaker Type: Combination AFCI / GFCI
  • Poles: 1-Pole
  • Series: CH
  • Mounting Type: Plug-in
  • Connection Type: Pigtail neutral
  • Compatible Panels: Eaton CH load centers and related equipment

Technical Specifications

  • Wire Size: AWG 14 – AWG 6 (Copper or Aluminum)
  • Tightening Torque: 20 lbf-in (2.3 N·m)

  • Dimensions:

    • Height: 1.2 in
    • Width: 0.75 in
    • Depth: 3.5 in

  • Weight: 0.5 lbs

  • Certifications: UL Listed

Product Data

  • Manufacturer: Eaton
  • Brand: Eaton
  • Model Number: CHFN120DF
  • UPC: 786689058852
  • Product Range: CH
  • Type Circuit Breakers
  • Vendor Eaton
  • Brand Eaton
