Eaton / Cutler‑Hammer UVH2LP08K 110‑127V Undervoltage Release – J‑Frame HMCP, Left‑Hand Mount

Description

The UVH2LP08K is a high-quality undervoltage release mechanism from Cutler Hammer (Eaton), designed for J-frame HMCP molded case circuit breakers. Operating at 110–127 V AC, this field-mounted device ensures reliable undervoltage tripping to protect your electrical systems. It features left-hand mounting and pigtail lead connections, making it compatible with J-K frame, Series C breakers. Built to meet industrial standards, the UVH2LP08K is UL listed for safety compliance.

Manufacturer: Cutler Hammer (Eaton)
Part Number: UVH2LP08K
Voltage Rating: 110–127 V AC
Frame Size: J-K Frame
Series: Series C
Mounting: Left-hand, field mounted
Connection Type: Pigtail leads
Type: Undervoltage release mechanism
Compatible With: J-frame HMCP molded case circuit breakers
Certifications: UL Listed
Weight: ~0.35–0.45 lbs
Dimensions: ~2.9" W x 2.5–2.9" H x 5.5–6.7" D

Specifications

• Part Number: UVH2LP08K

• Manufacturer: Cutler Hammer

• Category: Circuit Breaker Accessories

• Subcategory: Undervoltage Release

• Family: Series C

• Type: C

• Voltage: 110/127 V AC

• Amperage: 250 A

• Control Voltage Minimum: 110 V

• Control Voltage Maximum: 127 V

• Compatible Frames: JDB, JD, HJD, HJDDC, JDC, E2J, E2JM

Product Data

• UPC: 786679803547

• GTIN: 00786679803547

• Country of Origin: Dominican Republic

• Dimensions: Length 5.5 in × Height 2.9 in × Width 3.3 in

• Weight: 2 lbs

• Certification: UL
