Eaton CVS3150X CCV Tenant Main Breaker – 150A, 3-Pole, 42 kAIC

The Eaton CVS3150X CCV tenant main breaker is a molded case circuit breaker engineered for commercial tenant main and electrical distribution applications. It provides dependable thermal magnetic protection against overloads and short-circuit conditions while supporting high fault current interruption capability. Its three-pole configuration is suitable for multi-phase electrical systems requiring reliable power distribution protection.

Electrical Ratings

• Current Rating: 150A
• Number of Poles: Three-pole
• Interrupt Rating: 42 kAIC
• Circuit Breaker Frame Type: CV
• Breaker Type: Molded case circuit breaker

Key Specifications

• Manufacturer: Eaton
• Catalog Number: CVS3150X
• UPC: 786685704241
• Product Type: Tenant main breaker
• Standards: UL 489, CSA Std. C22.2 No. 5
• Wire Size Range: #6–4/0 AWG Cu/Al
• Terminal Capacity: #4/0 kcmil maximum load
• Application: Tenant main and commercial electrical distribution systems
• Warranty: Limited lifetime

Physical Details

• Product Length/Depth: 7.5 in
• Product Height: 5 in
• Product Width: 5 in
• Product Weight: 4.4 lb

Product Data

• Application: Commercial power distribution and tenant main protection
• Compatibility: Eaton CV frame systems
• Installation Use: Molded case breaker installation
• Function: Protects electrical systems from overload and short-circuit faults
• Safety Feature: High 42 kAIC interrupting capacity for enhanced fault protection
