Eaton EDH2125 Series C Molded Case Circuit Breaker – 125A, 2-Pole, 240VAC, 100 kAIC

The Eaton EDH2125 Series C molded case circuit breaker is designed for high-reliability protection in industrial and commercial electrical distribution systems. It delivers consistent thermal magnetic protection against overloads and short circuits, helping maintain safe operation of electrical equipment and downstream circuits. With a high interrupting capacity, it is well suited for applications where elevated fault currents may occur.

Electrical Ratings

• Current Rating: 125A
• Voltage Rating: 240 Vac / 125 Vdc
• Frequency Rating: 50–60 Hz
• Number of Poles: Two-pole
• Interrupt Rating: 100 kAIC at 240 Vac
• Trip Type: T186
• Circuit Breaker Frame Type: Complete breaker (Frame F)
• Circuit Breaker Type: ED

Key Specifications

• Manufacturer: Eaton
• Catalog Number: EDH2125
• UPC: 786679456422
• Product Type: Molded case circuit breaker
• Series: Series C
• Terminals: Load side
• Standards: UL Listed
• Warranty: Eaton Selling Policy 25-000

Physical Details

• Product Length/Depth: 3.38 in
• Product Height: 6 in
• Product Width: 2.75 in
• Product Weight: 3 lb

Product Data

• Application: Industrial and commercial power distribution protection
• Installation Use: Series C molded case breaker systems
• Function: Provides overload and short-circuit protection for electrical circuits
• System Compatibility: Designed for Eaton Series C distribution equipment
• Safety Feature: High interrupting capacity (100 kAIC) for reliable fault protection in demanding electrical environments
