Eaton Cutler-Hammer

Eaton FAZ-D20/3-RT FAZ Branch Protector – 20A, 3-Pole

In stock
SKU: FAZ-D20/3-RT GTIN/UPC: 015081021875
$151.20
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Eaton FAZ-D20/3-RT FAZ branch protector is designed to provide reliable circuit protection for industrial and commercial applications involving high inrush current loads. It is suitable for use in systems with motors, transformers, and other inductive loads where higher startup currents are expected. Built to IEC standards, it delivers precise magnetic and thermal protection for enhanced electrical safety and system reliability.

Electrical Ratings

  • Current Rating: 20A
  • Number of Poles: Three-pole
  • Trip Type: 10–20× (high inrush magnetic trip range)
  • Application Suitability: High inductive loads (motors, transformers, and similar systems)

Key Specifications

  • Manufacturer: Eaton
  • Catalog Number: FAZ-D20/3-RT
  • EAN: 4015081021871
  • Product Type: Branch protector
  • Terminals: Ring-tongue
  • Standards: IEC 60947-2, UL 1077, CSA C22.2 No. 235
  • Warranty: 1 year
  • Catalog Notes: Designed with enhanced magnetic range for high startup inrush applications

Physical Details

  • Product Length/Depth: 2 in
  • Product Height: 4.25 in
  • Product Width: 2.25 in
  • Product Weight: 1 lb

Product Data

  • Application: Motor control circuits, transformer protection, and inductive load systems
  • Installation Use: Branch circuit protection in industrial electrical panels
  • Function: Provides overload and short-circuit protection with high inrush tolerance
  • System Compatibility: Designed for FAZ series modular protection systems
  • Safety Feature: High magnetic trip range ensures stability during startup surges
  • Type Protector
  • Vendor Eaton Cutler-Hammer
  • Brand Eaton
