Eaton FD1015 Series C Molded Case Circuit Breaker – 15A, 1-Pole, 347VAC/125VDC, 18 kAIC

The Eaton FD1015 Series C molded case circuit breaker is designed for reliable protection in commercial and industrial electrical distribution systems. It provides thermal magnetic protection against overloads and short circuits, ensuring safe and stable operation of electrical equipment. Built on the Series C platform, it is suitable for applications requiring DC capability and higher voltage ratings in compact branch protection systems.

Electrical Ratings

• Current Rating: 15A
• Voltage Rating: 347 Vac / 125 Vdc
• Frequency Rating: 50/60 Hz
• Number of Poles: Single-pole
• Interrupt Rating: 35 kAIC at 277 Vac / 18 kAIC at 347 Vac
• Trip Type: T186
• Circuit Breaker Frame Type: Complete breaker (Frame F)
• Circuit Breaker Type: FD

Key Specifications

• Manufacturer: Eaton
• Catalog Number: FD1015
• UPC: 786679312100
• Product Type: Molded case circuit breaker
• Series: Series C
• Frame: F
• Terminals: Load side
• Standards: UL Listed
• Application Note: Suitable for AC and DC circuit protection applications within rated limits

Physical Details

• Product Length/Depth: 3.38 in
• Product Height: 6 in
• Product Width: 1.38 in
• Product Weight: 1.65 lb

Product Data

• Application: Industrial and commercial electrical distribution systems
• Installation Use: Series C breaker assemblies for AC/DC branch circuit protection
• Function: Provides overload and short-circuit protection for electrical circuits
• System Compatibility: Designed for Eaton Series C equipment
• Safety Feature: High interrupting capacity ensures reliable fault protection in demanding electrical
