Eaton FDE308032 Series C Electronic Molded Case Circuit Breaker – 80A, 3-Pole, 600VAC/250VDC, 35 kAIC

The Eaton FDE308032 Series C electronic molded case circuit breaker is designed for advanced protection in industrial and commercial electrical distribution systems. It features an electronic LSI trip unit that provides precise long-time, short-time, and instantaneous protection, ensuring enhanced coordination and system reliability. Built on the Series C platform, it is ideal for applications requiring accurate trip performance and high interrupting capacity in demanding electrical environments.

Electrical Ratings

• Current Rating: 80A
• Voltage Rating: 600 Vac / 250 Vdc
• Frequency Rating: 50/60 Hz
• Number of Poles: Three-pole
• Interrupt Rating: 65 kAIC at 240 Vac / 35 kAIC at 480 Vac
• Trip Type: Electronic LSI
• Circuit Breaker Frame Type: Complete breaker (Frame F)
• Circuit Breaker Type: FDE

Key Specifications

• Manufacturer: Eaton
• Catalog Number: FDE308032
• UPC: 786685112114
• Product Type: Electronic molded case circuit breaker
• Series: Series C
• Frame: F
• Terminals: Load side
• Standards: UL Listed
• Application Note: Provides adjustable electronic protection for improved coordination in complex systems
• Warranty: Eaton Selling Policy 25-000 (1 year from installation or 18 months from shipment, if applicable per listing context)

Physical Details

• Product Length/Depth: 3.38 in
• Product Height: 6 in
• Product Width: 4.13 in
• Product Weight: 4.2 lb

Product Data

• Application: Industrial and commercial electrical distribution systems
• Installation Use: Series C electronic breaker assemblies for advanced protection systems
• Function: Provides adjustable overload and short-circuit protection with electronic trip control
• System Compatibility: Designed for Eaton Series C equipment
• Safety Feature: High interrupting capacity with electronic trip precision ensures reliable system coordination and protection
