Eaton HMCP250L5C Series C Motor Circuit Protector – 250A, 3-Pole, 600V/250VDC

In stock
SKU: HMCP250L5C GTIN/UPC: 786679151068
$1,662.43
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Eaton HMCP250L5C Series C motor circuit protector is designed to provide reliable magnetic-only protection for industrial motor control applications. Engineered for use in demanding electrical systems, it delivers fast short-circuit protection for motors and branch circuits while allowing motor starting currents without nuisance tripping. Built for high-performance motor protection systems, it supports dependable operation in commercial and industrial environments.

Electrical Ratings

  • Current Rating: 250A
  • Maximum Voltage Rating: 600 V / 250 Vdc
  • Number of Poles: Three-pole
  • Magnetic Trip Range: 1125–2250 A
  • Frame Size: Frame J-K
  • Type: Motor circuit protector

Key Specifications

  • Manufacturer: Eaton
  • Catalog Number: HMCP250L5C
  • UPC: 786679151068
  • Global Catalog Number: HMCP250L5C
  • Product Type: Molded case circuit breaker accessory
  • Series: Series C
  • Terminals: Line and load
  • Terminal Material: Non-aluminum
  • Standards: UL Listed, CSA Certified
  • Warranty: Eaton Selling Policy 25-000 (1 year from installation or 18 months from shipment, whichever occurs first)

Physical Details

  • Product Length/Depth: 4.06 in
  • Product Height: 10 in
  • Product Width: 4.13 in
  • Product Weight: 12.5 lb

Product Data

  • Application: Industrial motor control and protection systems
  • Installation Use: Motor branch circuit protection assemblies
  • Function: Provides magnetic-only short-circuit protection for motors and associated circuits
  • System Compatibility: Designed for Eaton Series C motor protection systems
  • Safety Feature: Adjustable magnetic trip range allows reliable motor startup while protecting against high fault currents
  • Type Protector
  • Vendor Eaton Cutler-Hammer
  • Brand Eaton
