Eaton Cutler-Hammer

Eaton JGE3090FAG Series G Molded Case Circuit Breaker – 90A, 3-Pole, 600VAC/250VDC, 25 kAIC

In stock
SKU: JGE3090FAG GTIN/UPC: 782113962504
$872.10
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Eaton JGE3090FAG Series G molded case circuit breaker is designed for reliable protection in commercial and industrial electrical distribution systems. It provides dependable thermal magnetic protection against overloads and short circuits, helping ensure safe operation of connected electrical equipment. Built on the Series G platform, it supports multi-standard compliance and delivers strong interrupting performance for demanding power distribution environments.

Electrical Ratings

  • Current Rating: 90A
  • Voltage Rating: 600 Vac / 250 Vdc
  • Frequency Rating: 50/60 Hz
  • Number of Poles: Three-pole
  • Interrupt Rating: 65 kAIC at 240 Vac / 25 kAIC at 480 Vac / 18 kAIC at 600 Vac
  • Trip Type: T185
  • Circuit Breaker Frame Type: Complete breaker (Frame JG)
  • Circuit Breaker Type: JG

Key Specifications

  • Manufacturer: Eaton
  • Catalog Number: JGE3090FAG
  • UPC: 782113962504
  • Product Type: Molded case circuit breaker
  • Series: Series G
  • Frame: JG
  • Terminals: Line and load
  • Standards: UL Listed, CSA Certified, IEC Rated, CE Marked
  • Warranty: Eaton Selling Policy 25-000 (1 year from installation or 18 months from shipment, whichever occurs first)

Physical Details

  • Product Length/Depth: 3.44 in
  • Product Height: 7 in
  • Product Width: 4.13 in
  • Product Weight: 6.5 lb

Product Data

  • Application: Commercial and industrial electrical distribution systems
  • Installation Use: Series G breaker assemblies for high-performance protection
  • Function: Provides overload and short-circuit protection for electrical circuits
  • System Compatibility: Designed for Eaton Series G distribution equipment
  • Safety Feature: High interrupting capacity and multi-standard compliance ensure reliable fault protection in global applications
  • Type Circuit Breakers
  • Vendor Eaton Cutler-Hammer
  • Brand Eaton
