Eaton LDB3600FT35W 600A 3P Molded Case Circuit Breaker – LDB Frame – 600VAC

The Eaton LDB3600FT35W molded case circuit breaker is designed to provide advanced circuit protection for commercial and industrial electrical systems. Built on the reliable LDB frame platform, this breaker features an LSG non-interchangeable trip unit that provides adjustable long delay, short delay, and ground fault protection for enhanced system safety. With a maximum current rating of 600 amperes and high interrupting capacity, the breaker ensures dependable performance in demanding power distribution environments. It is suitable for reverse feed applications and supports customizable configurations through optional accessories and rating plugs.

Product Specification

• LDB Frame Style Molded Case Circuit Breaker
• LSG Function Non-Interchangeable Trip Unit
• Suitable for Reverse Feed Applications
• Maximum Current Rating: 600A at 40°C
• 3 Pole Configuration
• Rating Plug Not Included
• Standard Lug Type: Without Terminals

Technical Specification

• L – Adjustable Long Delay Pickup (via adjustable rating plug)
• S – Adjustable Short Delay Pickup with fixed short delay time (I²t response) or adjustable short time (flat response)
• G – Adjustable Ground Fault Pickup with adjustable ground fault delay (flat response)
• Adjustable Trip Setting: 5–10× Continuous Ampere Rating
• Bolt-On Connection Type
• Designed for industrial power distribution protection

Voltage and Ratings

• Rated Voltage: 600VAC @ 50/60Hz
• Interrupting Capacity:
• • 65kA @ 240VAC
  • 35kA @ 480VAC
  • 25kA @ 600VAC
  • 22kA @ 250VDC

Product Data

• Manufacturer: Eaton / Cutler-Hammer
• Warranty: One Year
• Frame Type: L
• Poles: 3
• Maximum Voltage: 600V
• Maximum Amperage: 600A
• Connection Type: Bolt-On
• Standard Lug Type: Without Terminals

Important Note

This breaker requires a rating plug in order to operate correctly, and it is not included with the unit. Please verify availability and pricing of the appropriate rating plug before placing an order if you require one to be installed. Product images typically represent a base model for identification purposes only. If accessories are purchased together with the breaker, they can be installed during order processing to meet your specific configuration requirements.
